Union Special 5200 GEO textile sewing machine

union_special_5200_a_b_geo_textiel_machine_spe The 5200 Series is a 2 thread portable with rugged, but simple design for easy maintenance.  The machines weights 14lbs and is ideal for closing bags that need 2 threads and also sewing medium to lightweight non-woven geotextile material.

  • 2 Threads
  • Bottom feed machine
  • Heavy duty design
  • 6.4 kilo (14 lbs)

Close a diversity of material:

  • Polypropylene
  • Multi-Wall Paper
  • Jute & Geotextile
  • Geomembranes
  • Geonet
  • Geosynthetic fabrics
  • (landfill caps and liners)

Portable Bag Closer Bag Stitcher Machine, Single Needle, 2-Thread  Chain Stitch, Half- Automatic Thread Cutter. Easy to Operate. Recommended for bag closing applications demanding high strength and tight closures for materials such as Polypropylene, Multi-Wall Paper, Jute & Geotextile,  Geomembranes, Geonet, Geosynthetic fabrics (landfill caps and liners).

Robust design works in the most hard outdoor conditions! Also ideal for closing bags containing feed, seed, chemicals, & agricultural products when a strong 2-thread closure is needed. It is also possible to connect artificial Lawn with the Newlong Industrial  NP-3(II). The possibilities with this hand held machine are versatile.
Technical Specifications

Model NP-3Ⅱ
Max. Speed 1,500rpm
Seam Double thread chain stitch (Type 401)
Stitch Width 8mm
Bag Material Paper・Jute・PP
Thickness Jute bag 10mm
Cutter Half automatic thread cutter
Needle DN×1 #25
Oiling by hand
Oil Machine oil #10
weight 8.5 kg
Related Machines crepe tape cutter (Special order)

※depending on sewing material and operation
